Netgear GS108E 8-Port Switch

Key features

• 8 ports provide gigabit Ethernet connectivity to your devices
• This switch is designed to optimize power usage, lowering cost of operation as a result
• Auto-MDI/MDIX eliminates the need for crossover cables
• Automatic connection at the highest common speed between the switch and an end device
• Silent operation makes this switch perfect for noise-sensitive environments
• Install your switch on your desktop, or mount it to your wall or rack with the hardware provided in the box

Specifications

Management features

• Switch type: Unmanaged
• Switch layer: L2/L3

Ports & interfaces

• Basic switching RJ-45 Ethernet ports quantity: 8
• Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)

Network

• Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
• 10G support: No
• Cable types supported: Cat5e, Cat6, Cat6+, Cat6a, Cat6e, Cat7, Cat7e, Cat8, Cat8.1
• Port mirroring: Yes
• Ethernet LAN data rates: 10,100,1000 Mbit/s
• VLAN support: Yes
• Virtual LAN features: Port-based VLAN, Tagged VLAN
• Number of VLANs: 64

Data transmission

• Switching capacity: 16 Gbit/s
• MAC address table: 4000 entries

Security

• Access Control List (ACL): Yes

Multicast features

• Multicast support: Yes
• Number of multicast groups filtered: 128

Design

• Product colour: Grey
• LED indicators: Activity, Link, Power, Speed, System

Performance

• Fanless: Yes
• Mean time between failures (MTBF): 2463431 h

Power

• Power source: DC
• Power supply included: Yes
• DC input voltage: 12 V
• Input current: 1.5 A
• Power consumption (max): 3.7 W

Operational conditions

• Operating temperature (T-T): 0 - 40 °C
• Storage temperature (T-T): -20 - 70 °C
• Operating relative humidity (H-H): 10 - 90%
• Operating altitude: 0 - 3000 m
• Heat dissipation: 8.9 BTU/h

Weight & dimensions

• Width: 158 mm
• Depth: 101 mm
• Height: 29 mm
• Weight: 508 g
