NEXO GEO M6B 6.5-inch Bass Module, White

The NEXO GEO M6B is a low and mid-frequency partner module designed to extend the GEO M620, delivering more powerful reinforcement for applications such as live music and touring sound reinforcement. It houses a single 6.5-inch 8Ω long-excursion driver in a lightweight polyurethane composite enclosure, finished in white.

The GEO M6B offers a usable frequency range of 75Hz–120Hz (±3dB, preset-dependent), 94 dB sensitivity and a maximum SPL of 125 dB, driven by a recommended 450 W amplifier at 8Ω nominal impedance. A flare-shaped port tube increases low-frequency efficiency and linearity at high output levels.

Connectivity is via 2x NL4 Speakon 4-pole inputs, with system control available through NEXO TDController. The cabinet shares the same physical footprint as the GEO M620, allowing the two modules to be arrayed together in a single column for flexible touring and installation configurations.

• 1x 6.5-inch 8Ω long-excursion driver
• 94 dB sensitivity, 125 dB maximum SPL
• 75Hz–120Hz ±3dB frequency response
• 373 x 191 x 260 mm, 7.6 kg
• 2-year warranty
