Netgear M4350-16C Managed Switch

Power and Throughput

Edge to core flexible platform, from 1 Gigabit to 100 Gigabit, good for projects of all sizes.

Groundbreaking AV GUI

A simplified user interface makes it easy to assign configuration profiles to each port.

Multicast in an Instant

NETGEAR IGMP Plus™ provides multicast functionality right out of the box for most AV over IP applications.

Sleek, Quiet Design

Less fan noise, and mounting ears included for rack mounting.

Automatic Configuration

Auto-trunk and auto-LAG functionality auto connects with other M4350 (and M4250) switches.

Fast, Easy

Configuration

for AV Pros

A streamlined interface using certified profiles with settings for any AV or broadcast application assigned to ports with just a few clicks.

F

ocus on the Event

Not the Fan Noise

Most models have quiet mode which greatly reduces fan noise.

Designed For AV Over IP

Right out of the Box

With built-in NETGEAR IGMP Plus™, there's little-to-no setup required for flawless audio and video delivery. Enable multicasting right out of the box.

PRO AV FAMILY COMPARISON

USE CASE

SWITCH STACKING

PoE CAPABLE

PORT SPEEDS

AVB SUPPORT

AV WEB UI / AV TEMPLATES

AV DESIGN

(FRONT LED'S & REAR CABLING)

M4250 SWITCH SERIES

Access/Edge

No

Yes

1, 2.5, 10Gbps

Yes*

Yes

Yes

M4350 SWITCH SERIES

Core/Access/Edge

Yes

Yes

1, 2.5, 10, 25, 100Gbps

Yes

Yes

No

M4500 SWITCH SERIES

Core/Access/Edge

No (MLAG)

No

1, 10, 25, 100Gbps

No

No

No

M4350-16C (CSM4316) Technical Specifications

WHAT'S INCLUDED

M4350-16C (CSM4316)

1

Power cord(s)

1

Console USB Type-C cable

1

Rack-mounting standard bracket set

1

Set of longer brackets for recessed mounting

1

Rubber footpads for tabletop installation

4

Installation guide

1

TECHNICAL DETAILS

Width

440mm

Depth

400mm

Height

43.2mm

Weight

8.03kg (17.70lb)

Primary Port Speed

100 Gigabit

Number of Ports

16 (16 x 100G QSFP28)

IGMP Support

Enhanced (NETGEAR IGMP Plus™)

Jumbo Frame Support

Yes, up to 12kb

AVB Support

Yes, included.

Acoustics

Quiet Mode 30.4dB@25ºC

Power Consumption

Maximum: 161.9W/552.40Btu/hr

Standby (no port connection): 69.1W/235.43Btu/hr

PSU Compatible Models

APS600Wv3A

APS1200Wv2

APS2000Wv2

MANAGEMENT

NETGEAR Engage Controller

Centralized application to configure all switches across your entire network. Lightweight and portable, you can run it from a USB thumb drive.

Learn More

SUPPORT & WARRANTY

Warranty :

This product is backed by NETGEAR limited lifetime hardware warranty.​

Click here

for coverage, availability and terms and conditions.

Support :

NETGEAR Support offers a customizable support experience based on your operational needs:​

Sprint support

option with 24/5 Technical Support (phone, online) and Advance RMA Replacement​

Overdrive support

option with 24/7 Technical Support (phone, online, 2h SLA) and Next Business Day RMA Replacement​

Support coverage in one, three, or five year contracts​

Visit

http://www.netgear.com/enterprise-support

for more information.
