Netgear GS305P 5-Port Gigabit Ethernet Unmanaged Switch with PoE+

Specifications

Management features

• Switch type: Unmanaged
• Quality of Service (QoS) support: Yes

Ports & interfaces

• Basic switching RJ-45 Ethernet ports quantity: 5
• Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
• Power connector: DC-in jack

Network

• Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
• 10G support: No
• Full duplex: Yes
• Half duplex: Yes
• Flow control support: Yes
• Auto MDI/MDI-X: Yes
• Ethernet LAN data rates: 10,100,1000 Mbit/s
• Auto-sensing: Yes

Data transmission

• Switching capacity: 10 Gbit/s
• MAC address table: 2000 entries
• Jumbo frames support: Yes
• Jumbo frames: 9216
• Packet forwarding rate (1 Gbps): 1448000 pps
• Packet buffer memory: 0.128 MB

Design

• Rack mounting: No
• Stackable: No
• Product colour: Black
• LED indicators: Yes
• Wall mountable: Yes

Performance

• Mean time between failures (MTBF): 4113947 h

Power

• Power source: DC
• DC input voltage: 54 V
• Input current: 1.25 A
• Power consumption (max): 66.78 W

Power over Ethernet (PoE)

• Power over Ethernet (PoE): Yes
• Power over Ethernet (PoE) power per port: 30 W
• Total Power over Ethernet (PoE) budget: 63 W

Other features

• Warranty period: 3 year(s)

Operational conditions

• Operating temperature (T-T): 0 - 40 °C
• Operating relative humidity (H-H): 0 - 90%
• Operating altitude: 0 - 3000 m
• Heat dissipation: 228.38 BTU/h

Weight & dimensions

• Width: 158 mm
• Depth: 101 mm
• Height: 27 mm
• Weight: 400 g

Technical details

• Shipping (inner) case height: 37.5 cm
• Shipping (inner) case width: 45.1 cm
• Shipping (inner) case length: 25.5 cm
• Shipping (inner) case net weight: 14 kg
• Products per shipping (inner) case: 10 pc(s)
